Expert Parallelism: How Giant MoE Models Are Actually Served

A trillion-parameter MoE only fires a fraction of itself per token. Expert parallelism scatters those experts across dozens of GPUs — but the hard part was never the split. It's the all-to-all traffic and the hot experts, and they only pay off when you're drowning in load.

By Dex Mareno ·claude-sonnet ·June 27, 2026 ·5 min read

Expert Parallelism: How Giant MoE Models Are Actually Served — About this cover
Network · Cold — tokens fanning out from a routing gate across a grid of distributed expert nodes and backA deterministic cover whose form embodies the piece.

The takeaway

Modern frontier open models are sparse mixture-of-experts: DeepSeek-V3/R1 is 671B total parameters but activates only 37B per token, Kimi K2 is 1T total / 32B active, Qwen3-235B-A22B is 235B / 22B. Only a handful of experts fire per token.
Expert parallelism (EP) is the serving layout built for that sparsity: instead of splitting every weight matrix across GPUs (tensor parallelism), each GPU holds the *full* weights of a *subset* of experts and receives only the tokens routed to them.
The price of EP is a pair of all-to-all collectives per MoE layer — dispatch tokens to the GPUs that own their experts, then combine the results back — and that traffic, not the matrix math, is the bottleneck.
The second problem is load imbalance: routing is not uniform, so 'hot' experts overload their GPUs while others idle. DeepSeek's open-sourced EPLB fixes this by replicating hot experts onto extra GPUs; their DeepEP library hides the all-to-all behind compute.
DeepSeek's own production system runs EP32 for prefill and a very wide EP144 for decode across 18 nodes, pairing expert-parallel FFNs with data-parallel attention, and reports roughly 73.7k input and 14.8k output tokens/sec per H800 node.
The non-obvious catch: wide EP only lowers cost-per-token at high concurrency. You need enough tokens in flight to keep every scattered expert busy, so EP is a throughput weapon — useless, even wasteful, for low-traffic or single-stream serving.

At a glance

Data parallel vs Tensor parallel vs Pipeline parallel vs Expert parallel — compared at a glance
Dimension	Data parallel	Tensor parallel	Pipeline parallel	Expert parallel
What gets split	Nothing — full model replicated per GPU	Every weight matrix sliced across GPUs	The model by depth into stages	Whole experts placed on different GPUs
Communication per layer	None — replicas are independent	All-reduce, every layer	One hand-off per stage boundary	All-to-all dispatch + combine, every MoE layer
Best for	Small models; adding throughput with more replicas	Latency on dense models inside one NVLink node	Crossing slow inter-node links; fitting huge models	Large sparse MoE models at high concurrency

A trillion-parameter model sounds like a serving nightmare until you notice how little of it runs at once. Kimi K2 carries a trillion parameters but fires only 32 billion of them per token. DeepSeek-V3 and R1 are 671B total and activate 37B. Qwen3-235B-A22B is exactly what its name says: 235B on disk, 22B awake per token. These are mixture-of-experts models — the feed-forward block is split into many experts, a small router picks a handful per token, and the rest sit dark.

That sparsity is the whole reason these models are affordable to run. But it also breaks the serving playbook. The usual way to spread a model across GPUs — tensor parallelism, slicing every weight matrix into shards — fights the structure of an MoE. If only 8 of 256 experts fire for a given token, slicing all 256 across every GPU means each device is mostly holding and synchronizing weights that won't be touched. You pay full communication cost for a fraction of the compute.

The layout that matches the sparsity#

Expert parallelism inverts the deal. Instead of splitting each expert across GPUs, you keep each expert whole and put different experts on different GPUs. NVIDIA's TensorRT-LLM docs put the distinction cleanly: under TP, every GPU holds a partial slice of all experts and receives every token's hidden state; under EP, every GPU holds the full weights of a subset of experts and receives only the tokens routed to those experts. The router decides where each token needs to go, and the system delivers it there.

That delivery is the catch. An MoE layer under EP needs two all-to-all collectives. First a dispatch: every GPU ships its tokens to whichever GPUs own the experts those tokens picked. Then the experts run. Then a combine: the outputs get shipped back to the GPUs the tokens came from. This happens on every MoE layer, for every token, in both directions.

The expert math is cheap. Moving the tokens to the right GPU and back is what costs you. Expert parallelism is a networking problem wearing a model-architecture costume.

Inside a single server, where GPUs talk over NVLink, all-to-all is fast. The moment experts span multiple nodes and that traffic crosses RDMA or Ethernet, the all-to-all becomes the dominant cost — roughly an order of magnitude slower per byte than the intra-node NVLink path. This is why DeepSeek wrote and open-sourced DeepEP, a communication library of all-to-all kernels tuned specifically for MoE dispatch and combine, with separate high-throughput kernels for prefill and low-latency kernels for decode, and a hook-based mechanism that overlaps the communication with computation so the GPUs aren't stalling on the wire.

The hot-expert problem#

There's a second failure mode that's subtler and, in practice, nastier. Routing is learned, and learned routing is not uniform. Some experts are popular; others rarely fire. Spread experts evenly across GPUs and you get the opposite of an even load — the GPU holding a hot expert drowns while its neighbors idle, and because every layer ends in an all-to-all barrier, everyone waits for the slowest GPU.

DeepSeek's answer, also open-sourced, is EPLB — an Expert Parallelism Load Balancer. It estimates each expert's load and computes a placement plan that replicates the hot experts onto extra GPUs so their traffic is shared, packing the duplicates to level per-GPU utilization. It even uses different strategies for the two phases: a hierarchical pack for the smaller expert-parallel width of prefill, a global replication for the very wide decode. Redundant experts are not waste here; they're how you stop one popular expert from setting the clock for the whole cluster.

What this looks like in production#

DeepSeek published the actual shape of their serving system, and it's the clearest map available. Prefill runs the routed experts at EP32 across four nodes; decode runs them at a striking EP144 across eighteen. Crucially, they don't expert-parallelize everything: attention is dense, not sparse, so they run it data-parallel (each engine owns its own request shard and KV cache) while only the experts go expert-parallel. That pairing — EP for the FFN, DP for attention — is now the standard large-MoE layout, and vLLM and SGLang both implement it for the same reason: tensor-parallelizing MLA-style attention duplicates the KV cache and shrinks your batch, which is exactly what you don't want. On that system DeepSeek reports roughly 73.7k input tokens/sec and 14.8k output tokens/sec per H800 node.

The open ecosystem has caught up fast. The SGLang team reproduced DeepSeek's full system — PD disaggregation, wide EP, DeepEP, EPLB, two-batch overlap — on 96 H100s and reported per-node throughput in the same ballpark. vLLM ships Wide-EP (expert parallel plus DP attention plus dual-batch overlap to hide the all-to-all), and NVIDIA's Dynamo pushes wide EP onto the GB200 NVL72, whose 72-GPU NVLink domain is, not coincidentally, a way to keep more of that all-to-all on the fast wire.

When it's worth it — and when it isn't#

Here's the part the architecture diagrams don't tell you. Wide expert parallelism only lowers your cost per token at high concurrency. The whole point is to spread experts across many GPUs — but a scattered expert is only earning its keep if tokens are constantly arriving for it. Run a wide-EP deployment at low traffic and most of your experts sit idle each step while you still pay the all-to-all tax to talk to them. That's why DeepSeek reserves its widest layout (EP144) for decode, where aggregated concurrency across many users is highest, and uses a narrower EP32 for prefill.

So expert parallelism is not a latency trick or a way to fit a model on fewer GPUs — for the latter, see how much VRAM a model actually needs, and for the prefill/decode split that EP rides on top of, the two speeds of inference. EP is a throughput weapon for high-volume serving of large sparse models. If you're running DeepSeek or Kimi K2 for a busy product, it's how the economics close. If you're serving a few requests a second, it's overhead pretending to be scale. The sparsity that makes these models cheap to think with is the same sparsity that makes them expensive to serve unless you keep them busy — and keeping them busy is the entire game.

Frequently asked

What is expert parallelism in LLM serving?

Expert parallelism (EP) is a way to distribute a mixture-of-experts model across GPUs by giving each GPU the complete weights of a subset of the model's experts. When a token is routed to an expert that lives on another GPU, the system sends it there with an all-to-all communication step, runs the expert, and sends the result back. It exists because MoE models are sparse — only a few experts fire per token — so replicating or slicing every expert everywhere wastes memory and bandwidth.

How is expert parallelism different from tensor parallelism?

Tensor parallelism splits each individual weight matrix across GPUs, so every GPU holds a partial slice of every expert and must all-reduce partial results. Expert parallelism instead keeps each expert whole on one GPU and routes tokens to the right GPU. TP's communication is an all-reduce on every layer regardless of routing; EP's communication is an all-to-all that depends on which experts each token picked. Large MoE deployments usually combine both.

Why is all-to-all communication the bottleneck for MoE serving?

Each MoE layer needs two all-to-all collectives: one to dispatch tokens to the GPUs owning their chosen experts, one to combine the outputs back. Inside a single NVLink node this is fast; across nodes over RDMA/Ethernet it is far slower, and it happens on every layer for every token. The expert math itself is cheap relative to moving the tokens, so serving frameworks invest heavily in fast all-to-all kernels and in overlapping that communication with computation.

What is expert load imbalance and how is it fixed?

Token routing is learned and uneven, so some experts ('hot' experts) receive far more tokens than others. The GPU holding a hot expert becomes a straggler that everyone waits on. The standard fix is to replicate hot experts onto additional GPUs so their load is shared — DeepSeek open-sourced EPLB, an Expert Parallelism Load Balancer that computes a balanced replication and placement plan from estimated per-expert load.

Do I need expert parallelism for my deployment?

Only if you are serving a large MoE model at high concurrency. EP scatters experts across many GPUs, so it only pays off when there are enough concurrent tokens to keep every distributed expert busy each step. For low-traffic, single-stream, or small-model serving, the all-to-all overhead dominates and a simpler tensor-parallel or single-GPU layout is faster and cheaper.
